model: HS-Y3-30
master chip processor Dual Core 32-Bit DSP(XM530AI), Pure Hard Compression, Watchdog
image sensor 3,000,001/2.8 "SC3335 CMOS sensor
operating system embedded LINUX operating system
Image encoding format Smart H.265X
APP Super Look (Support andriod and IOS)
Valid video pixels 3MP
resolution main code stream: 2304*1296 @ 12fps; Sub-code stream: 800*448 @ 12fps
Minimum illuminance 0.001LUX/F1.2
lens 3.6mm (standard)
perspective 89 °
Video Flip flip up and down/flip left and right
light control mode starlight infrared
fill lights 11 infrared diode lamps
pan-tilt control rotation angle level: 355; Vertical: 90
pan-tilt flip flip up and down/flip left and right
coding standard G.711
pickup support
horn support
video file size ≈6G/day
video recording method Manual video recording, dynamic detection video recording, timing video recording and alarm video recording
video preservation TF card/cloud
storage Cloud storage+TFlocal video recording (maximum support128GB)
Remote playback support
Capture function support
wireless network 2.4G WIFI 802.11b/g/n
Distribution network WiFi Smartlink distribution network addition, AP hotspot addition, two-dimensional code scanning
Ethernet 10/100Mbps RJ-45 interface
network protocol TCP/IP, ONVIF, RTSP
reset key support
humanoid tracking support
360-degree positioning support
power supply DC5V
applicable place homes, shops, supermarkets, factories and other places;
Installation method wall hanging and hoisting
operating temperature -20 ℃-+55
working humidity 10%-90%


3 million resolution, low illumination, clear and delicate image
Supports wireless and wired network connections
Support humanoid detection movement tracking
Support 2D/3D noise reduction, digital wide dynamic
Advanced H.265AI video compression technology, ultra-low code rate, high definition image quality
Lightning protection, in line with national standard GB/T17626.5, international standard IEC61000-4-5
Support ONVIF protocol, access to third-party backend/platform
Support mobile phone monito

Product details
